CuNi30Fe1Mn1NbSi-C ( CC383H )
| Gradd : | CuNi30Fe1Mn1NbSi-C |
| Rhif: | CC383H |
| Dosbarthiad: | Copper-nicel aloi |
| Safon: | EN 1982% 3a 2008 Copr a copr aloion. Cilgots a castings |
| Cyfwerth graddau: | Ewch yma |
Cyfansoddiad cemegol % o gradd CuNi30Fe1Mn1NbSi-C ( CC383H )
| A ôl-ddodiad -C yw ychwanegu i y dynodiad i inodi deunydd yn y ffurflen o castings |
| Ab | C | Mn | Ni | P | S | Ds | Al | B | Pb | Se | Mg | Zn | Te | Crynoddisg | - | ||
| 0.5 - 1.5 | max 0.03 | 0.3 - 0.7 | 0.6 - 1.2 | 29 - 31 | Uchafswm 0.01 | Uchafswm 0.01 | 0.5 - 1 | Uchafswm 0.01 | Uchafswm 0.01 | Uchafswm 0.01 | Uchafswm 0.01 | Uchafswm 0.01 | Max 0.5 | Uchafswm 0.01 | Uchafswm 0.01 | Uchafswm 0.02 | Cu - gweddill |
Mecanyddol eiddo o gradd CuNi30Fe1Mn1NbSi-C ( CC383H )
| Rm - Tensile cryfder (MPa) (GS) | 440 |
| Rp0.2 0.2% proof cryfder (MPa) (GS) | 230 |
| A - Min. elongation yn doriad (%) (GS) | 18 |
| Brinell caledwch (HBW): (GS) | 115 |
Cyfwerth graddau o gradd CuNi30Fe1Mn1NbSi-C ( CC383H )
Rhybudd! Only for reference
| UE EN |
Yr Almaen DIN,WNr |
||
| CuNi30Fe1Mn1NbSi-C |
|
Castio broses
| GS | Sand castio |
| GM | Parhaol llwydni castio |
| Centrifugal castio | |
| GC | Parhaus castio |
| Meddyg teulu |
Deunydd amodau
| R | Material condition designated by the minimum value of tensile strength requirement for the product with mandatory tensile strength and elongation requirements |
| H |
Priodweddau mecanyddol
| REh | Isafswm cynnyrch cryfder / Mindestwert der oberen Streckgrenze / Limite d elastigedd minimale |
| Rm | Tensile cryfder % 2f Zugfestigkeit % 2f Resistance a la traction |
| A | Lleiafswm elongation % 2f Mindestwert der Bruchdehnung / Allongement lleiaf |
| J | Notch effaith prawf / Kerbschlagbiegeversuch / Essai de flexion par choc |
|
CuNi30Fe1Mn1NbSi-C ( CC383H ) Copper-nicel aloi |
